船用电缆CHEPJP90/NC, CHEPFP90/NC
船用电缆CHEPJP90/NC,CHEPFP90/NC对数x2x截面积Noofpairsx2 xcrosssectionareaCHEPJP80/NC, CHEPFP80/NCCHEPJP85/NC,…
产品描述
船用电缆CHEPJP90/NC, CHEPFP90/NC
对数x2x截面积 No of pairs x 2 x cross section area | CHEPJP80/NC, CHEPFP80/NC | CHEPJP85/NC, CHEPFP86/NC CHEPJP95/NC, CHEPFP96/NC | |||||||||
外径 Overall diameter | 约重 Approx . weight | 外径 Overall diameter | 大约重量 Approx. weight | 外径 Overall diameter | 大约重量 Approx. weight | ||||||
标称 Nom. | 最大 Max. | 标称 Nom. | 最大 Max. | 80系列 | 90系列 | 标称 Nom. | 最大 Max. | 85系列 | 95系列 | ||
No.x 2xmm2 | kg/km | kg/km | kg/km | kg/km | kg/km | ||||||
1x2 x 1.5 2x2 x 1.5 3x2 x 1.5 4x2 x 1.5 5x2 x 1.5 7x2 x 1.5 10x2 x 1.5 12x2 x 1.5 14x2 x 1.5 16x2 x 1.5 19x2 x 1.5 24x2 x 1.5 27x2 x 1.5 30x2 x 1.5 33x2 x 1.5 37x2 x 1.5 43x2 x 1.5 48x2 x 1.5 | 11.2 18.2 19.6 21.6 23.9 26.4 34.6 36.1 38.2 40.4 42.8 51.1 52.4 54.6 56.8 59.3 64.8 68.8 | 12.5 20.0 21.5 24.0 26.5 29.0 38.0 39.5 41.5 44.0 46.5 55.5 57.0 59.0 62.0 64.5 70.5 74.5 | 180 357 492 625 770 1036 1502 1766 2039 2298 2694 3440 3831 4235 4617 5146 5983 6688 | 12.8 19.8 21.2 23.2 25.5 28 36.7 38.2 40.3 42.5 44.9 53.2 54.5 56.7 58.9 61.4 66.9 70.9 | 14.0 22.0 23.0 25.5 28.0 30.5 40.0 41.5 43.5 46.0 49.0 55.0 59.0 61.0 64.0 66.5 72.5 76.5 | 284 527 680 836 1006 1306 1958 2252 2561 2857 3298 4171 4596 5043 5468 6051 6989 7772 | 273 508 660 813 982 1279 1911 2203 2509 2802 3240 4102 4525 4970 5392 5971 6901 7679 | 14.9 22.3 23.7 25.9 28.2 30.9 40 41.7 43.8 46.2 48.6 57.3 58.8 61 63.4 65.9 71.8 76 | 16.5 24.5 25.5 28.5 30.5 33.5 43.5 45.0 47.0 50.0 52.5 62.0 63.5 65.5 68.5 71.0 77.5 82.0 | 340 625 780 952 1129 1444 2167 2478 2789 3111 3553 4510 4953 5402 5859 6440 7458 8286 | 328 607 760 930 1105 1418 2120 2429 2737 3056 3495 4441 4882 5329 5783 6360 7371 8193 |
